IC-KP-B7-V95
Anhang B
Ausgangs-Instanz 109d - 56 Bytes
Bytes
0 - 11
12 - 23
24 - 35
36 - 47
48 - 55
Ausgangs-Instanz 110d - 136 Bytes
Bytes
0 - 31
32 - 63
64 - 95
96 - 127
128 - 135
Ausgangs-Instanz 111d- 248 Bytes
Bytes
0 - 59
60 - 119
120 - 179
180 - 239
240 - 299
Ausgangs-Instanz 112d - 0 Bytes
Bytes
NONE
Klasse, Instanz, Attribut
64h, 01d, 02h
64h, 02d, 02h
64h, 03d, 02h
64h, 04d, 02h
64h, 05d, 01h
Klasse, Instanz, Attribut
64h, 01d, 03h
64h, 02d, 03h
64h, 03d, 03h
64h, 04d, 03h
64h, 05d, 01h
Klasse, Instanz, Attribut
64h, 01d, 04h
64h, 02d, 04h
64h, 03d, 04h
64h, 04d, 04h
64h, 05d, 01h
Klasse, Instanz, Attribut
N/A
Beschreibung
Channel 1 [12]
Channel 2 [12]
Channel 3 [12]
Channel 4 [12]
IDENT Control
Beschreibung
Channel 1 [32]
Channel 2 [32]
Channel 3 [32]
Channel 4 [32]
IDENT Control
Beschreibung
Channel 1 [60]
Channel 2 [60]
Channel 3 [60]
Channel 4 [60]
IDENT Control
Beschreibung
Heartbeat
91
