Mechanical Installation - nVent RAYCHEM Elexant 5010i Bedienungsanleitung

1. INSTALLATION
For installation/operation, always observe the Equipment Safety Law, the rules of generally accepted engineering practice
EN
(IEC60079-14/EN 60079-14), and the instructions stated in this Manual. Carry out work on the thermostats in the de-energized state only.
DE
1.1 Mechanical installation
FR
Elexant 5010i-LIM units comprise a temperature controller and a safety temperature limiter installed in one enclosure. The controllers
can be installed in any position on a stable structure by means of the 4 mounting holes. Up to a pipe temperature of 210°C the
RU
Elexant 5010i and Elexant 5010i-LIM units can be mounted directly on the pipe by means of a support bracket type SB-125. Ensure that
the ambient temperature of the equipment does not exceed 60°C at any time. In order to provide enough stability, the support bracket
shall be attached by means of 2 pipe straps.
Figure 4: Mounting positions Elexant 5010i(-LIM)
1.1.1 Connecting cables and cable glands to Elexant 5010i and Elexant 5010i-LIM units.
Installation instructions for glands (threaded holes only)
At ambient temperatures > 45°C the selected cable should have a temperature rating of 80°C or higher. Cable glands with a
temperature rating of 80°C or higher should be selected.
2xM16x1.5
3xM20x1.5
Figure 5
Tolerance class
Enclosure material limitations
Maximum surface roughness of the
enclosure wall
|
8 nVent.com/RAYCHEM
Un it e а
ol iqu
e Co ntr g ctr
tur un e Ele
era ith eiz aç ag
mp gle ur Tr om
ing Te für Be e po en t.c
ac ler tur nV
at- Tr reg éra а
He era tur Te mp
mp ur de
Te ôle
ntr а
Co
i Б
1 0
s / П
5 0 e dem ent
n t Ex cor
e / Rac
x a chl üss
s / Ans
E le tion
Con nec
s / П
ent
i cor dem
Ex e / Rac
üss
chl
s / Ans
tion
Con nec
3xM25x1.5
Tolerance class for Ex e glands is maximum 6G/6H.
When plastic glands are used, only plastic glands made from flame retardant, high
impact resistant polyamide shall be used. The glands shall be suitably certified for the
intended area of use.
Better than 3,2 µm is recommended.
Maximum level of surface roughness allowed is Ra 6 µm;
