Communications
Physical network
Protocol/topology
Cable and maximum length
Maximum quantity of controllers in
one network
(Modbus) Network address
Configuration and setting
Method
Units of measure
Memory
LED indicators
Elexant 5010i
Elexant 5010i-LIM
Measuring ranges
Temperature range controller
Temperature range limiter
Voltage
Load current
Ground fault current
Heater time alarm
Relay cycle alarm
Ordering information
Product name
Elexant 5010i
Elexant 5010i-LIM
Elexant 5010i (EAC)
Elexant 5010i-LIM (EAC)
Elexant 5010i accessories
Temperature sensors
Product name
Support bracket for installation on pipe
Product name
Bluetooth enabled handheld programming device with customized software
See for more information Android tablet TAB-Ex datasheet and Elexant Connect operations manual
RS-485 and Class 1 Bluetooth
Modbus RTU or ASCII. Multi drop/Daisy Chain
Shielded twisted pair cable, 0.5 mm² (AWG 24) or larger. Total cable length from first till last
device shall not be more than 1200 m.
Max. 247 devices per field communication network
Software configurable via nVent RAYCHEM Android tablet application
Through handheld programming device or via nVent RAYCHEM Supervisor software/User
Interface (TOUCH 1500, NGC-UIT)
°C or °F, software selectable
Nonvolatile. There is no loss of parameters after the event of power outage or long term shut
down. Data holding time ~10 years.
Status LEDS are available for:
Heater, Alarm, RS-485 communication, Bluetooth communication.
Heater, Alarm, Limiter (tripped), RS-485 communication and Bluetooth.
From –200°C to +700°C in steps of 1 K
From +50°C to +599°C in steps of 1 K (Elexant 5010i-LIM only)
From 90 Vac to 305 Vac
From 0.1 A to 25 A
From 10 mA to 500 mA (RCD/ELCB required due to IEC and/or local regulations).
From 1 to 1x 10 hours
6
From 0 to 2x 10 operations
6
Part number
2000002132
2000002133
2000002370
2000002369
MONI-PT100-260/2
MONI-PT100-EXE
MONI-PT100-EXE-SENSOR
SB-125
EAN number
5414506023138
5414506023145
5414506023152
5414506023169
