BORETTI CFBI902AN2 Montage- Und Gebrauchsanweisungen Seite 223

Fig. 7.15
B
Fig. 7.16
Fig. 7.17
Fig. 7.18
A
G
CLEANING THE INNER PANES OF
GLASS
The oven door is fitted with no. 3 panes:
• no. 1 outside;
• no. 1 inner;
• no. 1 in the middle.
To clean all panes on both sides it is
necessary to remove the inner and the
middle panes as follows:
REMOVING THE MIDDLE AND
INNER PANES OF GLASS
1. Lock the door open:
Fully open the oven door (fig. 7.15).
•
• Fully open the lever "A" on the left and
right hinges. (fig. 7.16).
• Gently close the door until left and
right hinge levers "A" are hooked to
part "B" of the door (figs. 7.16, 7.17).
2. Remove the inner pane:
Gently remove the air deflector "G" at
•
the top of the oven door (fig. 7.18).
• Gently pull out the inner pane of glass
(fig. 7.19).
• Clean the glass with an appropriate
cleaner. Dry thoroughly, and place on
a soft surface.
Fig. 7.19
223
