BATTERY TESTER_________________________________________________________________________
NOTE:
This is the battery's capacity rating that is usually found on the battery's label.
Depending on the battery, use any of the following:
CCA - cold cranking ampere rating.
CA / MCA - cranking ampere / marine cranking ampere rating.
A-HR - ampere hours.
DIN - German-Duetche industry norm.
JIS - Japanese industrial standard.
6. After selecting a capacity rating, press the GO key. This displays a screen for
entering the capacity rating.
7. Use the Up and Down Arrow keys and adjust the rating until it matches the
rating on the battery's label.
NOTE:
Do not use the rating reported by the Quick Test because it is typically higher than the
printed rating for a newer battery.
8. Press the GO key to begin the test. The screen displays First Load On, Recovery
Period, Second Load On, Recovery Period, and then Working as it applies
two medium loads to the battery followed by recovery periods.
NOTE:
If the tester senses abnormal conditions, such as a cold battery, other screens may
display. Respond to any questions as necessary.
9. Wait for the screen to display "Proceed with Starting/Charging Test?"
10. Do one of the following:
To start the test, press the Up Arrow key and continue with the next step.
To stop the test, press the Down Arrow key. This displays the Battery Test
results. For instructions, refer to step 9 on chapter 3.2.
48
SET CCA= 600
'GO' TO ACCEPT
PROCEED WITH
STARTING/CHARGING
TEST?
YES NO
OPERATING INSTRUCTIONS
