Pixsys ATR244 Installationsanleitung Seite 151

Tabella parametri di configurazione
GRUPPO A - A. i n. 1 - Ingresso analogico 1
1 Sensor AI1
SEN. 1
2 Decimal Point 1
d.P. 1
3 Degree
deGr.
4 Lower Linear Input AI1
L.L. i . 1
5 Upper Linear Input AI1
u.L. i . 1
6 Potentiometer Value AI1
P.vA. 1
7 Linear Input over Limits AI1
i.o.L. 1
8 Offset Calibration AI1
o.cA. 1
9 Gain Calibration AI1
G.ca. 1
10 Latch-On AI1
Ltc. 1
11 Conversion Filter AI1
c.FL. 1
12 Conversion Frequency AI1
c.Fr. 1
13 Lower Current Error 1
L.c.E. 1
14÷17 Reserved Parameters - Group A
GRUPPO B - A. i n.2 - Ingresso analogico 2 (solo su ATR244-23XX-T)
18 Sensor AI2
SEN.2
19 Decimal Point 2
d.P. 2
20 Reserved
rEs.
21 Lower Linear Input AI2
L.L. i .2
22 Upper Linear Input AI2
u.L. i .2
23 Potentiometer Value AI2
P.vA.2
24 Linear Input over Limits AI2
i.o.L.2
25 Offset Calibration AI2
o.cA.2
26 Gain Calibration AI2
G.ca.2
27 Latch-On AI2
Ltc.2
28 Conversion Filter AI2
c.FL.2
29 Conversion Frequency AI2
c.Fr.2
30 Lower Current Error 2
L.c.E.2
31÷34 Reserved Parameters - Group B
GRUPPO C - cmd. 1 - Uscite e regolaz. Processo 1
35 Command Output 1
c.ou. 1
36 Command Process 1 (solo su ATR244-23XX-T)
c.Pr. 1
37 Reserved
rEs.
38 Action type 1
Ac.t. 1
39 Command Hysteresis 1
c.HY. 1
40 Lower Limit Setpoint 1
L.L.S. 1
41 Upper Limit Setpoint 1
U.L.S. 1
42 Command Reset 1
c.re. 1
43 Command State Error 1
c.S.e. 1
44 Command Led 1
c.Ld. 1
45 Command Delay 1
c.de. 1
46 Command Setpoint Protection 1
c.S.p. 1
47 Valve Time 1
vA.t. 1
48 Automatic / Manual 1
a.ma. 1
49 Initial State
ini.S.
50 State Valve Saturation
S.vA.S.
51 Initial Value Setpoint 1
i.SP. 1
52÷53 Reserved Parameters - Group C
109
109
109
109
109
110
110
110
110
110
110
110
110
110
111
111
111
111
111
111
112
112
112
112
112
112
112
112
113
113
114
114
114
114
114
114
114
114
115
115
115
115
115
115
115
115
Manuale d'uso - ATR244 - 151
