Connection cable
Connection cable with M12 F connector, 8‐pin, TPU IP67, PUR
cable sheath, 5 m long
Connection cable with M12 F connector, 8‐pin, TPU IP67, PUR
cable sheath, 20 m long
Connection cable with M12 F connector, 8‐pin, stainless steel
IP68/IP69K, hygiene design, 3 m long
Connection cable with M12 F connector, 8‐pin, stainless steel
IP68/IP69K, hygiene design, 6 m long
For connection cable specifications, see separate data sheet B3643.
Pin assignment 1-KAB168
Color code
White
Red
Blue
Pink
Green
Gray
Yellow
Brown
16
Connection
Measurement signal (+)
Measurement signal (-)
Excitation voltage (+)
Excitation voltage (-)
Sense lead (+)
Sense lead (-)
Not in use
Not in use
A05202_02_Y00_01 HBM: public
1-KAB168-5
1-KAB168-20
1-KAB177-3-1
1-KAB177-6-1
PW27AP
