If after programming the remote control the direction of the roller shutter movement does not correspond to the required
one (pressing the "▲" key lowers the roller shutter), then delete the remote control from the memory of the electric motor
(see section 4.4) and re-program it, but during programming press the "▼" key instead of the "▲" key (see above).
Alternatively, change the direction, see section 5.4. In this case, the limit positions must be deleted prior to that.
4.2 Recording additional remote controls
The electric motors provide the possibility of remote recording of additional remote controls. To record the second and
subsequent remote controls, it is necessary to be in the immediate vicinity of the electric motor to which you want to
assign an additional remote control. New remote controls will be recorded on all receivers within the operating range, in
which the remote control has already been registered, if it is necessary to record a new remote control to only one of the
electric motors, the rest should be disconnected.
• To record the second and subsequent remote controls, press the "P2" button on the already recorded remote control 2
times, after each pressing a short beep will sound, then, on the new remote control, press the "P2" button 1 time. After that,
5 short beeps will sound and the electric motor will make a short reverse movement.
4.3 Grouping control of several electric motors on a single remote control
Control of a group of electric motors from a single remote control is possible when this remote control is recorded as an
additional one (section 4.2) in each electric motor in turn.
4.4 Deleting remote controls
Electric motors allow deleting all remote controls ever recorded into the motor memory. To accomplish this, it is necessary
to delete every recorded remote control from the memory.
• To delete a remote control from the motor memory, disconnect the motor from the supply mains. Connect the motor to
the supply mains (it is possible to delete remote controls within the first 10 sec. after connecting the motor to the supply
mains).
• Press 3 times "P2" key, then press 3 times the control key "■" and again press 3 times "P2" key. A short beep sound should
follow each key press, and 3 short beeps will be heard and the motor will make a short reverse movement after the last key
press.
5. LIMIT ADJUSTMENT
The upper and lower limits are the end positions of the roller shutter, within which it will move during further use and
beyond which its exit is not permissible. Before using the roller shutter, it is necessary to set the restrictions for the roller
shutter.
ATTENTION! Stop the movement of the roller shutter curtain in time when setting the limits!
Since the tube of the electric motor on an unconfigured roller shutter can rotate indefinitely, damage
to the roller shutter components is possible if the roller shutter gets into the box completely or the
suspension system is destroyed if the roller is excessively unwound.
It is not allowed to operate the AM0/R-Sm, AM1/R-Sm series electric motors with incorrect or not set
limits, this may result in damage to the components!
To avoid damage during adjustment, the roller shutter must be in direct line of sight. Go to the push-button switch, or take
the radio remote control and make sure that you can see the roller shutter well enough.
Password for setting using the mobile interface: 1998. By entering the password, you confirm that you are familiar with the
above safety measures and that you are aware of the risk of damage to the structure.
5.1 Manual adjustment of limit switches using a radio remote control
The setting is carried out only with the help of the remote control recorded in the memory of the electric motor. A short
bees will be heard before you start driving if the limits are not set.
• Press the "P2" key, then press "▲" and then press "P2" key again. Each key press will be followed by a short beep
sound, and the last key press will be followed by 3 short beeps, and the motor will make a short reverse movement.
• Press "▼" key and then using the "■" key stop the roller shutter curtain in the desired lower limit position.
• Press and hold "■" key for 5 seconds, the key press will be followed by 3 short beep sounds, and the motor will make a
short reverse movement – the lower limit position is set.
• Press "▲" key and then using the "■" key stop the roller shutter curtain in the desired upper limit position.
• Press and hold "■" key for 5 seconds, the key press will be followed by 3 short beep sounds, and the motor will make a
short reverse movement – the upper limit position is set.
The adjustment of limit switches completed. Raise and lower the roller shutter curtain fully several times using the "▲"/
"▼" keys, make sure the curtain travels smoothly and the upper and lower limit positions are set correctly.
