DRYWALL SCREWDRIVER
PTBS 520 A1

Introduction

Congratulations on the purchase of your new appli-
ance. You have chosen a high-quality product. The
operating instructions are part of this product. They
contain important information about safety, usage
and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.

Intended use

The appliance is intended for rational, simple and
fast screwing in and unscrewing of drilling, drywall
and wood screws.
Use this product only as described and for the
areas of applications specified. The appliance is
not intended for commercial use. Any other usage
or modification of the appliance is deemed to be
improper and carries a significant risk of accidents.
The manufacturer accepts no responsibility for
damage(s) attributable to misuse.

Features

Belt clip
Locking button
ON/OFF switch
Speed preselection
Rotation direction switch
Tool holder
Screw (for adjusting the screw length)
Screw (for adjusting the screw depth)
Magazine attachment
Screw bit 150 mm (PH2)
Screw bit 25 mm (PH2)
Bit adapter
Depth stop sleeve
Adjusting ring
Lower belt guide
Screw belt
Upper belt guide
Screw stop
■ 2 │ GB│IE│NI│CY

Package contents

1 drywall screwdriver PTBS 520 A1
1 magazine attachment
1 depth stop sleeve
2 screw belts (each with 50 screws 3.5 x 25 mm)
2 screw bits (25 mm/150 mm)
1 bit adapter
1 set of operating instructions

Technical data

Drywall screwdriver:
PTBS 520 A1
Rated voltage:
Rated power
consumption:
Rated no-load speed: n
Max. torque:
Tool holder:
Protection class:
Magazine attachment:
Screw size:
–
Screw length:
–
Max. shaft ø:
–
Max.
screw head Ø:
Screw-in depth:
Depth stop sleeve:
–
Max. screw head Ø:
230 V ~ , 50 Hz
(AC)
520 W
0–4500 rpm
0
8 Nm
1/4" hexagon socket
(6.35 mm)
II / (double insulation)
25/30/35/40/41 mm
6 mm
9.5 mm
3 screw depths
(continuously variable)
9.5 mm
PTBS 520 A1
