that the juice can flow out more easily and the appliance does not clog.
• It is common that when processing apples and bananas, the juice squeezed is not completely pure.
Juicing
Note: The appliance can only be switched on if all
components of the appliance are correctly seated.
1. Place the appliance on a stable surface.
2. Place the pulp container on the side of the appliance
body.
3. Place the bowl with the juice outlet on the upper part of
the appliance body (Fig. 1).
4. Insert the strainer into the bowl with juice outlet by
pushing the top edge of the strainer downwards (Fig.
2).
5. Insert the auger (Fig. 2).
6. Place the top cover and secure it (Fig. 3). Place
a container for collecting squeezed juice under the
juice outlet.
7. Move the mode switch to the "-" position.
8. Slowly insert washed pieces of fruit and vegetables into the inlet.
You can insert whole apples and pears or cut into large pieces. You don't have to peel them or remove the core.
Remove the peel from the citrus fruits, insert only individual balls of grapes. When juicing currants, you can insert
whole bunches.
It is difficult to obtain juice from bananas, avocados, blackberries, figs, aubergines, strawberries, etc.
Notice: Always use a supplied pusher to push food through the inlet. Never push food with your fingers, fork,
spoon, knife or other object.
9. Continuously check the amount of pulp in the pulp container, the amount of pulp stuck to the top lid, and the
throughput of juice outlet. There must be no clogging of the juice outlet. Wait until the rotary strainer filter stops
before opening the top cover. Turn to loosen the top cover, clean it, empty the pulp container, clean the rotary
strainer and remove any pulp residue from the juice outlet cover.
CAUTION!
If there is a significant increase in noise during the juicing process or stronger vibrations occur, clean the appliance
immediately!
After use, switch off the appliance, disconnect it from the electrical outlet, remove the remaining pulp and clean
the individual components (see the Cleaning and maintenance section).
Warning: The finished juice is intended for immediate consumption because it oxidises very quickly in the air,
which may deteriorate its taste, change colour and, above all, reduce its nutritional value. Apple or pear juice turns
38
Fig. 1 Fig. 2
Fig. 3
brown quickly, you can slow down the process by adding a few drops of lemon juice.
Warning: In case of food jamming of the appliance, turn the mode switch to the "R" position = off. After releasing
the food, continue juicing.
NOTICE: IF THE APPLIANCE JAMS AND STOPS WORKING,
SWITCH IT OFF. PRESS THE RESTART BUTTON ON THE
BOTTOM AND THEN MOVE THE SWITCH TO THE "R"
POSITION FOR A FEW SECONDS. IF YOU CANNOT UNJAM
THE APPLIANCE, IT MUST BE DISASSEMBLED AND
CLEANED.
To eliminate squeaking noises that may come from the
auger placed in the cover, add a drop of oil to the tip of
the auger.
The juice container is not designed to preserve juice or other foods!
When juicing fruit or vegetables that contain little water (older apples, kiwis, etc.), it is recommended
to continuously insert harder fruit and vegetables, such as carrots, to clean the container, strainer and
drain hole.
CAUTION!
Only insert stoned and properly washed frozen fruit. If there is a significant increase in noise during the juicing process
or stronger vibrations occur, clean the appliance immediately!
Use frozen fruits such as: strawberries, raspberries, blueberries, bananas, etc.
Do not use fruit with stones, nuts or ice cubes.
Self clean
To facilitate cleaning, we recommend closing the drain plug after the juicing / ice cream preparation process is
completed. Use the mode switch to select the "Self clean" program and pour approx. 400 ml of water through the
opening of the top cover. After 1-2 minutes, open the plug and allow the water to flow out into the prepared container.
If necessary, you can repeat the procedure.

CLEANING AND MAINTENANCE

Before each cleaning of the appliance, unplug the power cord from the electrical outlet!
To clean the surface of the appliance, use only a damp cloth, no detergents or hard objects, as they can damage the
surface of the appliance!
Wash removable parts in warm water. Use the brush provided.
Never clean the appliance body under running water, do not rinse it or immerse it in water!
1. Open the top cover.
2. Release the bowl with juice outlet upwards together with the rotary strainer.
3. Remove and clean the pulp container.
4. After cleaning the removable parts, assemble the appliance in the reverse order.
LO721X LO721X
