MPS Version Ctrl For OS
This item specifies which version of MPS (Multi-Processor Specification) this motherboard will
use. Leave this item at its default setting.
Delay For HDD (Secs)
This item allows the BIOS to support some old or special IDE devices by prolonging this delay
time. A larger value will give more delay time to the device for which to initialize and to prepare
for activation.
Full Screen LOGO Show
This item determines to show the full screen logo when booting.
2.4 Advanced Chipset Features
► DRAM Configuration
► HT Link Control
► PCIe Configuration
Init Display First
↓↑→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
DRAM Configuration
Click <Enter> key to enter its submenu.
You may manually set the DRAM timing parameters through its sub-items, or leave them at
their default settings according to the SPD (Serial Presence Detect) data stored in the DRAM.
HT Link Control
Click <Enter> key to enter its submenu. You may manually set the parameters through each
sub-item, or leave them at their default settings.
PCIe Configuration
Click <Enter> key to enter its submenu. You may manually set the parameters through each
sub-item, or leave them at their default settings.
Init Display First
This item allows you to choose the primary display card.
2-8
All manuals and user guides at all-guides.com
Phoenix – AwardBIOS CMOS Setup Utility
Advanced Chipset Features
Press Enter
Press Enter
Press Enter
PCI Slot
F6: Fail-Safe Defaults
Item Help
F7: Optimized Defaults
AX78
