2.1 SoftMenu Setup

This option configures the CPU's clock and voltage.
AMD Phenom(tm) 9600 Quad-Core Processor
Frequency : 2300MHz
CPU Operating Speed
x - CPU External Clock(MHz)
x - Multiplier Factor
x - NB/SB A-LINK Clock
x - PCIe x16 Clock
x - PCIe Clock
Voltages Control
x - CPU Core Voltage
x - CPU Core NB Voltage
x - DDR2 Voltage
x - DDR2 Reference Voltage
x - NB 1.8V Voltage
x - NB 1.1V Voltage
x - SB 1.2V Voltage
x - Hyper Transport Voltage
x - V1P2 Dual Voltage
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
Brand Name
This item displays the CPU model name installed on this motherboard.
Frequency
This item displays the current CPU frequency.
CPU Operating Speed
This item displays the motherboard operating speed according to the following menu
combination. You can also select the [User Define] option to enter the manual option.
User Define:
The wrong settings of the multiplier and external clock in certain
※
circumstances may cause CPU damage. Setting the working frequency higher
than the PCI chipset or processor specs, may cause abnormal memory module
functioning, system hangs, hard disk drive data lose, abnormal functioning of
the VGA card, or abnormal functioning with other add-on cards. Using
non-specification settings for your CPU is not the intention of this explanation.
These should be used for engineering testing, not for normal applications.
There will be no guaranty for the settings beyond specification. Any damage of
※
any component on this motherboard or peripherals resulting therein is not our
responsibility.
- CPU External Clock(MHz)
This item selects the external clock frequency. Due to the specification limit of the CPU you
installed, the speed you set over its standard bus speed is supported, but not guaranteed.
- Multiplier Factor
(appears only with AM2 CPU)
This item
2-2
All manuals and user guides at all-guides.com
Phoenix – AwardBIOS CMOS Setup Utility
SoftMenu Setup
Default
200
x11.5
100
100
100
Default
+0.000V
+0.0V
1.80 V
0.0%
1.800 V
1.100 V
1.2000 V
1.20 V
1.2000 V
F6: Fail-Safe Defaults
displays the multiplier factor for the CPU you installed.
Item Help
F7: Optimized Defaults
