CPU FAN Type
This item selects your CPU fan type.
[4 Pin]: Leave this item at its default [4 Pin] setting for connecting a 4-pin cooling fan to the
"CPUFAN1" fan power header.
[3 Pin]: For a 3-pin cooling fan connection, you must configure this item to [3 Pin] in order to
have the speed control function enabled.
A mismatched configuration will cause the fan speed control function out of
※
order. Please select the correct option according to your fan type.
-
FanEQ Target Temp.
This item sets the temperature mark for the "CPU FanEQ" function to take effect.
-
FanEQ Temp. Tolerance
This item sets the temperature tolerance range for the item "FanEQ Target Temp.".
-
FanEQ Start Control
This item sets the speed ratio for the 4-pin CPU fan assembly connected at "CPUFAN1" fan
power connector to start running.
-
FanEQ Stop Control
This item sets the lowest speed ratio for the 4-pin CPU fan assembly connected at "CPUFAN1"
fan power connector to run at when the CPU temperature detected is lower than the value of
item "FanEQ Target Temp." plus the value of item "FanEQ Temp. Tolerance".
In the situation when the CPU temperature detected is higher than the value of item "FanEQ
Target Temp." plus the value of item "FanEQ Temp. Tolerance", the speed ratio for the 4-pin
CPU fan assembly connected at "CPUFAN1" fan power connector will first run at the speed ratio
set by the item "FanEQ Start Control", and then up to 100%.
SYS FANEQ Control
This item allows you to control the SYSFAN speed. When set to [Enabled], the following items
become selectable.
-
FanEQ Select Source
This item sets the reference point for taking temperature. The options are "System" and "CPU".
-
FanEQ Target Temp.
This item sets the temperature mark for the "SYS FanEQ" function to take effect.
-
FanEQ Temp. Tolerance
This item sets the temperature tolerance range for the item "FanEQ Target Temp.".
-
FanEQ Start Control
This item sets the speed ratio for the 3-pin fan assembly connected at "SYSFAN1" fan power
connector to start running.
AX78
All manuals and user guides at all-guides.com
2-15
