1. Hardware Setup

1.1 Specifications

CPU
• Supports Socket AMD AM2+/AM2
Processor using Hyper Transport™
Technology up to 5200MT/s
* AM2+ running HT3.0 5200MT/s
* AM2 running HT1.0 2000MT/s
• Supports AMD CPU Cool 'n' Quiet
Technology
Chipset
• AMD 770 / SB600
Memory
• 4x 240-pin DIMM slots support
maximum memory capacity up to 8GB
• Supports Dual Channel DDR2 1066
Un-buffered ECC/Non-ECC memory
* DDR2 1066 is supported by AM2+ CPU only.
LAN
• Onboard Gigabit LAN
Audio
• Onboard 7.1-Channel HD Audio CODEC
• Supports Auto Jack Sensing and S/PDIF
Out
Serial ATA
• 4x SATA 3Gb/s supports SATA RAID 0,
1, 0+1
Expansion Slots
• 1x PCI-E X16 Slot (X16 Bandwidth)
• 1x PCI-E X16 Slot (X4 Bandwidth)
• 1x PCI-E X1 Slot
• 3x PCI Slots
Specifications and information contained herein are subject to change without
※
notice.
AX78
All manuals and user guides at all-guides.com
Internal I/O Connectors
*
Rear Panel I/O
*
abit Engineered
RoHS
Miscellaneous
• 1x Floppy port
• 1x Ultra ATA 133 IDE connector
• 4x SATA 3Gb/s connectors
• 3x USB 2.0 headers
• 1x FP-Audio header
• 1x CD-In connector
• 1x S/PDIF Out Header
• 1x PS/2 Keyboard connector
• 1x PS/2 Mouse connector
• 1x External CMOS Clearing Switch
• 1x Optical S/PDIF Out Connector
• 1x 7.1-Channel Audio connector
• 4x USB 2.0 connectors
• 1x RJ-45 LAN connector
™
• abit Softmenu Technology
™
• abit Silent OTES Technology
• External CMOS Clearing Switch
• 100% Lead-free process and RoHS
compliant
• ATX form factor (305mm x 245mm)
• Vista Premium HW Ready
1-1
