Route the camera connection cable into the vehicle.
Connect the camera connection cable to the extension cable
(see ✎ L 16 ).
Route the connection cable from the camera to the switchbox/monitor
(see ✎ H 3 und L 13).
Insulate the plug conection with the sealing tape provided
(see ✎ L 16 and L 17).
Securely fasten the cable in the vehicle to provent entanglement (risk
of tripping) using binders, insulating tape (see ✎ L 14 und L15) or by
gluing with adhesive.
Do not start sealing the holes until all camera setting work has been
completed and the required connection cable lengths have been
determined.
Attention: The plug connection to the camera is not moisture
protected. It is very important to seal the connection using the
sealing tape provided to prevent any damage.
For the parts required for laying the cable from the camera to the
monitor see ✎ L 13 to L 15.
Further extension cables are available from your dealer or from WAECO
on request:
Length Art. No.
5 m RV-505
8 m RV-508
20 m RV-520
46
Laying the cables
