(see ✎ E)
1 POWER Operation ON/OFF
2 MODE Selection of the video source (input 1 or 2)
3 VR Volume and setting within a function
4 MUTE Mute
5 AUTO PIC Invokes the 4 picture presettings
6 RECALL Displays the current volume / video channal
7 MENU Menu selector switch for calling up the various menus
8 PRO Switch for selecting the functions within a menu
Warning! Choose the monitor position such that it cannot cause
injury to the driver or passengers under any circumstances (sudden
braking, road accident).
Ensure that the monitor does not impair the driver's vision in any
way (see ✎F 1).
General installation instructions!
Observe the following points before fitting the monitor:
– Screw the monitor holder onto the monitor.
– Try out the position of the monitor with holder and stand attached.
– When choosing the monitor position, ensure that it can be clearly
viewed by the driver (no obstructions) (see ✎ F 2 and F 3).
– Ensure that the installation site is level.
– Before finally installing check whether there is sufficient space
underneath the selected installation site for fitting the washers and
nuts.
– Take the weight of the monitor into consideration. Are reinforcements
(larger washers or plates) required?
– Is it possible to route the connection cable set and extension cable to
the monitor?
Perform a function test before installation.
The stand is equipped with self-adhesive tape which provides sufficient
hold if the installation surface is level and clean. Use the 3 screws
provided for safety. Use a 2-mm bit to drill the pre-marked holes, and
screw the stand tight. The stand can also be mounted on slightly curved
surfaces. The stand plate can be easily bent to achieve the required
shape (see ✎ F 4).
