When positioning the monitor ensure that it is not installed within the
effective area of one of the AIRBAGS. Otherwise inflation may cause
injury.
Ensure that the contact surface between the stand plate and installation
surface is as large as possible.
Draw an outline of the monitor stand on the dashboard.
Mark the 3 points for the drill holes.
Producing the opening for the monitor connection cable
(see ✎ F 5)
When routing the connection cable through openings (see ✎ F 5.1)
use, as far as possible, original grommets or other feedthrough
possibilities such as e.g. trim edges, ventilation grids or dummy
switches. If there are no holes available, drill a Ø 15 mm hole
(see ✎F 5.2). Check beforehand that there is sufficient clearance
for the drill bit to emerge on the other side.
Drill a Ø 15 mm hole behind the monitor (see ✎ F 5.2).
Deburr all drill holes in sheet metal and treat with rust proofing agent.
Apply grommets to all sharp-edged holes.
Insert the connection cable into the socket until it engages audibly.
Route the connection cable and extension cable under the
dashboard. Ensure that the cable is not under strain.
Position the monitor with the threaded bush on the monitor holder and
use the knurled screw in the monitor holder to fix the monitor in
place.
For parts required for fastening the monitor see ✎ F 6.
Installing the monitor
