The following articles can be delivered as accessories.
Designation
Extension cable, 5 m
Extension cable, 8 m
Extension cable, 20 m
Helix cable for trailer operation
Swan neck mount for monitor
Colour camera
Installation bracket for monitor console
Vehicle specific monitor consoles
All rights for technical modifications and availability withheld!
Front (see ✎ D)
1 Operating switch (Power)
2 Menu selector switch, calls up the various menus
3 Switch for selecting the functions within the menu
4 Volume control (2 buttons for loud or quiet) and setting within a
function
5 Switch for function selection (selection of video input 1 or 2).
Input 1 is always the connection to the camera RV-27
6 Infrared receiver for the remote control of the monitor
7 Stand-by display (no picture)
Rear (see ✎ D)
8 Loudspeaker
9 Socket for the connection cable
Delivery scope
Assembly set
Screws with 2 pre-assembled washers
(camera holder)
Screws with fixed washer
Adhesive tape
Sealing tape for plug connection
Cable fastening clips
Tapping screws with 2 washers
(camera holder)
Accessories for RV-58

Monitor

(sun-hood)
(camera holder)
Article No.
RV-505
RV-508
RV-520
RV-500-SPK
RV-500-SH
RV-27
Monhol
Various (on request)
