Safety and installation instructions

Warning! Improper cable connections may result in short circuits
which can cause:
– cable fires
– triggering of the airbag
– damage to electronic control equipment
– failure of electrical functions (blinkers, brake lights, horn,
ignition, lights)
Please note the following:
The following terminal designations apply for work on the vehicle
cables:
30 (input from battery positive direct)
15 (switched positive, behind battery)
31 (return cable from battery, earth)
58 (reversing lights)
The securest form of connecting is by soldering the cable ends and then
insulating the connection.
For releasable connections, use only insulated cable brackets, connector
plugs and tabs. Do not use lustre terminals.
For connecting the cables with cable brackets, plugs or tabs, use crimping
pliers.
For cable connections to 31 (earth):
Attach the cable with a bracket and toothed washer to an earthing
screw on the vehicle or screw it onto the metalwork of the vehicle using
a bracket, metal screw and toothed washer.
Always ensure a good earthing connection!
Warning! Because of the risk of short circuits, always disconnect
the negative pole of the battery before starting work.
In case of vehicles with a supplementary battery, also disconnect
this negative pole.
Caution! On disconnecting the negative pole of the battery, all the
volatile memories of the convenience electronics will lose their
stored data.
