Mounting / fitting (see ✎ H 1).
Installation / cable connection (see ✎ H ).
Attention! If the vehicle height or length registered in the vehicle
documents is altered by the installation of the camera, it is
necessary to have the vehicle reinspected by the responsible
authorities (TÜV, DEKRA etc.). Have your vehicle documents
amended accordingly.
Warning! Select the position of the outside camera and fasten it
securely to exclude the risk of injury to persons standing near the
vehicle (by branches scraping over the roof).
As the outside camera has to be positioned at least 2 m high to
ensure a suitable viewing angle, make sure that the workplace is
suitably secure.
General fitting instructions!
Before fitting the outside camera, observe the following points:
– The outside camera has to be positioned at least 2 m high to ensure a
suitable viewing angle.
– Ensure that the installation point for the outside camera is suitably
secure (e.g. branches scraping over the vehicle roof could catch on
the camera).
– Fit the camera in a horizontal and central position at the rear end of
the vehicle (see ✎ I 1).
Please route the camera cable so that the plug connection between the
camera and connection cable is easily accessible in case it becomes
necessary to dismantle the camera. This considerably facilitates
dismantling.
The most secure method for fastening the camera is by means of screws
which go through the construction, whereby there are several points to
consider:
1. Does the selected position offer sufficient clearance underneath for
the installation?
2. Any form of opening / hole requires suitable measures preventing the
penetration of water (e.g. by inserting the screws with sealing
compound and / or sealing the external fastening elements with
sealing compound).

Installation

Fitting the outside camera
