The Set includes a ready-for-use 12 V power cable with cigarette lighter
socket. Plug the jack socket into the input POWER of the monitor and
the cigarette lighter socket into the cigarette lighter plug. The System
is ready for use.
For a direct connection to the electrical net of the vehicle disconnect
the cigarette lighter socket and connect the power cable with the
white-black wire to terminal 15 (ignition +) and the black wire to
terminal 31 (ground –).
Connect the stand-by cable to the back light signal.
The words in brackets are to be found on the monitor and/or remote
control.
1 POWER (POWER) – If the switchbox is used, this function is not
available (switching function via switchbox).
2 MENU (MENU) – This key is used for invoking the main menu
(see G 2). The keys
individual menu topics within the menus. The selected menu topic
changes colour to pink.
selecting the functions in the submenu, e.g. language.
The menu AUTOBILD USER is a special feature (see
which the user can create and store his personal picture setting.
After selecting the menu topic AUTOBILD USER press the MENU key
again. Setting graphics concerning brightness etc. appear. Press the
keys (VOLUME/VR) to select the functions (see
3 Program (PROG) – these keys are used for selecting the submenus.
4 Volume (VOLUME/VR) – These keys are used for controlling:
– the volume
– the functions in the submenu
5 If the switchbox is used, this function is not available (switching
function via switchbox).
Additional functions of the remote control:
MUTE – switches the loudspeaker silent
RECALL – displays the current setting of the loudspeaker and video input.
40

Operation

(PROG) can be used for selecting the
The keys (VOLUME/VR) are used for
G 3) with
G 4–9).
