Technical data
11.1
StecaGrid Control I1
Input side 230 V AC
Data
Output side 230 V AC
Main switch
Display
Dimensions (H x D x W)
Weight
Own consumption
Safety
Residual current monitor-
ing
Standards and certification marks
EMC: Emission EN 50081-1 (EN 55014 and EN 55022)
Interference immunity EN 50082-1
Safety EN 60950
Self-test As per DK5940
Degree of protection IP 20
Grid monitoring Direct component monitoring as per DK5940
Certification mark CE mark
1)
Both connection plugs are supplied with the inverter.
2)
DC sensitivity suitable for StecaGrid 300/500.
11.2
StecaGrid Remote
Display
Transceiver
Power supply
Range
Dimensions (H x D x W)
Weight
Standards and certification marks
HF transmission EN 300 220
Degree of protection IP 20
11.3
AC cables and line circuit breakers
AC cable conductor cross-section
2
1,5 mm
2
2,5 mm
52
AC connection (Wieland Electric GST 18i3V
1)
1P1)
1)
Steca data connection
AC contact plug (Wieland Electric GST 18i3V);
Mating plug included in delivery.
Yes
Yes
250 x 175 x 70 mm
1.75 kg
2.7 W
The plant must be equipped with an AC/DC sen-
sitive residual current protection switch type B
in accordance with DIN VDE 0100-410.
of StecaGrid Control I1
868 MHz ISM
2x LR06 (AA)
approx. 100 m indoors
approx. 300 m outdoors
140 x 103 x 35 mm
0.23 kg
Line circuit breaker
B16
B16 or B25
