Technical Data And Functional Description; Technical Data; General Description - Comprag DV75 Bedienungsanleitung

2.

Technical data and functional description

2.1

Technical data

Article Model
11300105 DV7508
11300106 DV7510
11300115 DV9008
11300116 DV9010
* Measured according to ISO 1217; ** Measured according to ISO 3744

2.2 General description

The DV-Series oil-filled screw compressor series is designed for uninterrupted and efficient
compressed-air production.
The DV-Series compressor is an electric motor-operated, intake-regulated, direct-driven and
air-cooled compressor, enclosed in a sound-insulated canopy. An electronic controller v-Log
with an LCD indicator panel is provided, including start and stop buttons and an emergency
stop button. Pressure and temperature relays are used for system control and protection.
COMPRAG Screw air compressor DV-Series
Entitlement to free handling of faults arising during the guarantee
period is forfeited when:
- No warranty service coupon for the compressor or it is filled out
incorrectly
- No records for the compressor's scheduled maintenance are
entered in the compressor's service book
- Unoriginal parts and lubricants are used
