5.5

Changing air-oil separator

2
Fig. 5.5 Changing air-oil separator
5.6

Cleaning radiator

Fig 5.6. Cleaning radiator
30
1
The separating component is located
within the separator tank. Open the
front panel in order to change it.
Unscrew the bolts (2) and carefully
remove the top cap of the tank.
Disconnect hoses if they make it
difficult to remove the cap. Remove the
spent separator and install a new one
in its place. Refasten the tank cap.
Open the left side panel.
Regularly clean the radiator in order
to maintain its cooling efficiency at an
acceptable level.
Remove any dirt particles from the
radiator using a fibre brush, then aim
a jet of compressed air at the radiator
from the bottom to the top; the jet should
be held at an approximate 90° angle to
the plane of the radiator.
