3.2 Dimensions
H
D
3.3 Requirements on installation facility
Fig. 3.3 Installation facility proposal DV75 – 90.
1. Air inflow
2. Air outflow
Ensure that the floor of the facility can withstand the weight of the compressor. Install the
compressor on a level surface that is able to bear its weight. Adjust the horizontal axis of the
compressor using a levelling instrument. If the compressor is not anchored to the base on
which it is installed, the tilt angle with respect to the horizontal surface must not exceed 3°.
16
L
1500
Fig. 3.2 Dimension drawing DV75 – 90.
Model
Length
L, mm
DV75
2550
DV90
DV75
2760
DV90
1500
1500
Compressor dimensions
Width
Height
D, mm
H,mm
1260
1880
Packaging dimensions
1360
2010
2
Version 1.4
Weight,
kg
2200
2370
2285
2455
1
