2. Automatic mowing status
3. Time
4. Mobile radio signal (RMI 422 PC)
1. Charge state:
The battery symbol serves to
indicate the charge state.
No bars – battery discharged
1 to 5 bars – battery partially
discharged
6 bars – battery fully charged
During charging, the mains plug
symbol is shown instead of the
battery symbol.
2. Automatic mowing status:
When automatic mowing is switched
on, the Automatic symbol appears.
3. Time:
The current time is indicated in 24-hour
format.
4. Mobile radio signal:
The signal strength of the
mobile radio connection is
indicated using 4 bars. The
more bars visible, the better
the reception.
A reception symbol with a
small x indicates that there is
no connection with the
Internet.
A question mark is shown
during initialisation of the radio module
(checking hardware and software,
e.g. after switching on the robotic mower).
0478 131 9963 F - EN
11.4 Main menu
The main menu is displayed,
– when the status screen (
is left by pressing the OK button,
– when the Back button is pressed in the
second menu level.
1. Start ( 11.5)
Mowing time
Starting pt.
Mowing on
2. Drive home ( 11.6)
3. Mowing plan ( 11.7)
Automatic mowing
Mowing duration
Active times
New mowing plan
4. More ( 11.8)
Lock iMOW®
Edge mowing
Settings
Information
11.5 Start
1. Mowing time:
The mowing time can be defined.
11.2)
2. Starting pt.:
The starting point where the robotic mower
starts mowing can be selected. This
selection is only available if starting points
are defined and if the robotic mower is in
the docking station.
3. Mowing on:
The area to be mown can be selected.
This selection is only available if there is a
secondary area installed.
11.6 Drive home
The robotic mower travels back
to the docking station and
charges the battery. If automatic
mowing is switched on, the
robotic mower will mow the mowing area
again at the next possible active time.
RMI 422 PC:
The robotic mower can also be sent
back to the docking station using
the app. ( 10.)
139
