Dimensional drawings and measurements

VGL 06.1200/1600/2100 DP
with gas valve MBVEF 412 and MBVEF 420
D
H
D
MBVEF 412 160
MBVEF 420 —
D
H
Space requirements
There should be a space of no less
than 0.8 metre on each side of the
burner for maintenance purposes.
Gas valve assembly
The valve assembly can be fitted on the
left or the right.
E
E H
590 Rp2
690 —
E
06/2011 - Art. Nr. 13 018 118C
KM
KL
KN
EN
KM
KL
KN
31
