10 Mounting of soffit elements PP 45 LE, PP 45 LEV and PP 45 LEW90 | UK
5. Fix soffit element to wall (e.g. with moun-
ting adhesive). Alternatively, screw soffit
element to wall with suitable screws or
wind clamping band around at 2 to 3 loca-
tions and screw to the wall.
6. Remove two-part stainless steel grille
[4] and [5] before mounting work commen-
ces.
7. Press stainless steel holder [4] into soffit
duct and carefully screw down with the 4
stainless steel Spax screws [4.2] provided
(but not too tightly). Ensure that the holder
is sealed completely at the bottom.
Wall seal [4.1] protects against leaka-
i
ges and prevents any condensate pro-
duced from getting behind the plaster.
8. Only mount soffit external grille [5] once
the plastering is complete.
Formation of surface rust: External
i
factors (e.g., air containing sulphur
dioxide or salt, dust containing iron
etc.) may cause surface rust to form
on stainless steel. We recommend
thoroughly cleaning unpainted stainless
steel parts before mounting (remove
dust and fingerprints) and rubbing in a
little oil (e.g. care oil for stainless steel).
When mounting external grilles made of
stainless steel, use only stainless steel
screws.
