EN
FAQ
Problem Type Solution
Robot does not perform The robot has low battery. Scheduled cleaning will not start unless the robot has been
scheduled cleaning
recharged in time.
Does leaving the robot
on the charging dock Leaving the robot on the charging dock after it's fully charged consumes very little
consume power if it is
electricity and helps maintain optimal battery performance.
already fully charged?
Confirm that the water tank is filled with water, and clean the mop pad if necessary.
No water comes out of
Clean the mop if it becomes dirty.
the mopping module, or
Make sure the mop pad is installed correctly according to the user manual.
only a little bit comes out
Clean the blowhole on the top of the water tank.
Make sure the robot is not set to Do Not Disturb Mode, which will prevent it from
resuming cleaning.
Robot doesn't resume
cleaning after charging
The robot does not resume cleaning when it is manually recharged or placed onto the
charging dock.
Moving the robot may cause it to re-position itself or re-map its surroundings. If the
Robot doesn't return to
robot is too far from the charging dock, it might not be able to automatically return
charging dock after being
on its own, in which case you need to manually place the robot onto the charging
moved
dock.
18
Specifications
Robot
Model RLS5-BL1
Battery 5200 mAh (Battery Nominal Capacity)
Charging Time Approx. 6 hours
Wireless
Wi-Fi IEEE 802.11b/g/n 2.4 GHz
Connectivity
Rated Voltage 14.4 V
Rated Power 40 W
Operation
2400-2483.5 MHz
Frequency
Maximum Output
＜ 20 dBm
Power

WEEE Information

All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should
not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over
your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed
by the government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the
environment and human health. Please contact the installer or local authorities for more information about the location as well
as terms and conditions of such collection points.
Charging Dock
Model
RCS0
Rated Input
100-240 V ~ 50/60 Hz 0.5 A
Rated Output 19.8 V 1 A
Under normal use of condition, this equipment should be kept a
separation distance of at least 20cm between the antenna and
the body of the user.
EN
19
