General

3.2.2 WEZ-6

3
10
9
8
53100347 / 53100439
1
2
7
6
4
5
11 / 29
1 Suspension eye for crane
hook
2 Suspension for suspension
eye (with centre of gravity
compensation and
suspension position for
empty and load lift)
3 Support arm with
adjustment holes for centre
of gravity compensation
4 Automatic change
5 Handle
6 Support profile
7 Gripper jaws
8 Support plate
9 Gripper jaws (adjustable)
10 Crossbar with adjustment
holes for gripping range
adjustment
