Jacobsen Eclipse 118 Technisches Handbuch Seite 125

Item Part No.
446116
1
2 2000148
3 2811071
4 2811223
5 2811107
6 3001273
7 2811110
7 4140154
8 4102241
9 4104641
10 2811108
11 4152677
12 4160533
13 463029
14 367554
15 446130
16 444708
17 400190
18 452006
19 446134
20 443106
21 434023
22 400262
23 453011
24 446142
25 443110
26 434034
27 400106
28 434031
29 403744
30 359864
31 366707
32 443806
33 452002
34 434042
Qty. Description
2 Lockwasher, #10
1 Bracket, Bearing
1 Belt, Polychain, 80 Tooth
1 Pully, 18 Tooth
1 Pully, 112 Tooth
1 Shaft
1 Fixed Head Pulley Cover
1 Floating Head Pulley Cover
1 Cover, Belt
1 Belt, 130 Tooth
1 Pulley, 23 Tooth
1 Mount, Motor
1 Motor, Brushless Bi-Directional
1 Key, Woodruff
2 Bearing, Needle
3 Lockwasher, 1/4 Heavy
3 Locknut, 1/4-20 Center
2 Screw, 5/16-18 x 1-1/4" Hex Head
1 Flat Washer, 5/16
1 Lockwasher, 5/16
1 Nut, 5/16-18 Hex
1 Screw, 14-20 x 1-1/4" Socket Head
2 Screw, 3/8-16 x 1" Hex Head
2 Flat Washer, 3/8
2 Lockwasher, 3/8 Heavy
2 Nut, 3/8-16 Hex
2 Screw, 10-24 x 1" Socket Head
3 Screw, 1/4-20 x 5/8" Hex Head
1 Screw, 1/4-20 x 3/4" Socket Head
3 Screw, #10-24 x 1/2" Hex Head
AR Thrust Washer
1 Ball Bearing
2 Nut, 5/16-24 Hex Jam
3 Flat Washer, #10
2 Screw, 1/4-20 x 1-1/2" Socket Head
ECLIPSE
Serial Numbers/Notes
Used on 63300, 63302, 63305,
63311, 63313 and 63315
Used on 63301, 63303, 63312 and
63314
Reference M1, See 22.1
Used on 63301, 63303, 63312 and
63314
> Change from previous revision
77
