Jacobsen Eclipse 118 Technisches Handbuch Seite 115

Item Part No.
4108920
1
1 1004990
2 4108924
2 3010422
3 3010286
4 3010712
5 4168727
5 4136994
6 4174683
6 4114788
7 352726
8 453023
9 446128
10 443102
11 400108
12 4140152
13 4140151
14 471221
15 460312
16 366317
17 4104720
18 4160533
19 4167400
20 4169040
20 4138778
21 4140162
22 4140166
23 434024
24 434010
25 443110
26 443112
27 445785
28 471214
29 446142
30 453011
31 463029
32 845279
33 REF
34 4156930
35 2812384
36 403782
37 REF
38 446130
Qty. Description
1 Rear Roller - 18"
1 Rear Roller - 22"
1 • Shaft, 18"
1 • Shaft, 22"
2 • Seal
2 • Bearing
1 Roller Mount - 18"
1 Roller Mount - 22"
1 Grass Catcher, 18" Floating Head
1 Grass Catcher, 22" Floating Head
2 Bushing
9 Flat Washer, 1/4
4 Lockwasher, 1/4 Med.
5 Nut, 1/4-20 Hex
4 Screw, 1/4-20 x 3/4" Hex Head
1 Mount, Right Side Catcher
1 Mount, Left Side Catcher
1 Grease Fitting, 1/4-28 90°
4 Hairpin
1 Rod End, 3/8-24
1 O-Ring, Motor
1 Motor, Brushless Bi-Directional
1 Plate, Motor Adapter
1 Rod, Panhard, 18"
1 Rod, Panhard, 22"
1 Ball Joint, Inline Linkage
2 Pin, Threaded
4 Screw, 5/16-18 x 3/4" Socket Head
3 Screw, 1/4-20 x 1-3/4" Socket Head
2 Nut, 3/8-16 Hex
2 Nut, 3/8-24 Hex
1 Nut, 3/8-24 Left Hand Hex
2 Grease Fitting
5 Lockwasher, 3/8 Heavy
5 Flat Washer, 3/8
1 Key, Woodruff
1 Seal, O-Ring
1 Reel Assembly
2 Screw, 3/8-24 x 1" Special
1 Coupler
1 Screw, 1/4-20 x 3/4" Truss Head
1 Reel Ground Wire
1 Lockwasher, 1/4 Heavy
ECLIPSE
Serial Numbers/Notes
Used on 63301 and 63314
Used on 63303 and 63312
Used on 63301 and 63314
Used on 63303 and 63312
Used on 63301 and 63314
Used on 63303 and 63312
Used on 63301 and 63314
Used on 63303 and 63312
Reference M2, See 22.1
Used on 63301 and 63314
Used on 63303 and 63312
See 11.1
Part of Harness 4165060
> Change from previous revision
67
