Jacobsen Eclipse 118 Technisches Handbuch Seite 105

Item Part No.
4165282
1
2 2811104
3 4167383
3 4165280
3 4168022
4 4168401
4 4165281
4 4168023
5 400258
6 446142
7 366796
8 400262
9 400260
10 400268
11 443810
12 4127931
13 REF
14 4117466
15 1000018
15 132674
15 1000019
16 444850
17 364164
18 4169840
19 4174680
Qty. Description
1 Frame, R.H. Side
1 Frame, L.H. Side
1 18" Front Crossbar
1 22" Front Crossbar
1 26" Front Crossbar
1 18" Rear Crossbar
1 22" Rear Crossbar
1 26" Rear Crossbar
6 Screw, 3/8-16 x 3/4" Hex Head
10 Lockwasher, 3/8 Heavy
2 Kickstand, Mounting Bracket
2 Screw, 3/8-16 x 1" Hex Head
3 Screw, 3/8-16 x 7/8" Hex Head
2 Screw, 3/8-16 x 1-3/4" Hex Head
4 Nut, 3/8-16 Hex Jam
1 Decal, Patent
1 Serial Plate
1 Decal, 96 db Noise
1 18" Kickstand
1 22" Kickstand
1 26" Kickstand
3 Nut, 3/8-16 Center Lock Jam
1 Spring
1 Decal, Danger
1 Decal, Weight
ECLIPSE
Serial Numbers/Notes
Used on 63300 and 63313
Used on 63302 and 63311
Used on 63304 and 63315
Used on 63300 and 63313
Used on 63302 and 63311
Used on 63304 and 63315
Used on 63300 and 63313
Used on 63302 and 63311
Used on 63304 and 63315
> Change from previous revision
