VOLTCRAFT VC-OBD-9610 Bedienungsanleitung Seite 43

1 Display
2 OK button
Confirms the selection of menu items, actions, etc.
3 ESC button
Cancels a selection or stops an action, or returns to the menu.
4 button
Navigates to the left in the menu or takes you one step back in the menu.
5 button
Navigates to the right in the menu or takes you one step forward in the menu.
6 button
Navigates up in the menu or moves the menu view up (if the whole view does not fit on a
screen).
7 button
Navigates down in the menu or moves the menu view down (if the whole view does not fit
on a screen).
8 ODB II connector
Connects the diagnostic scanner to the vehicle's data interface (OBD II interface).
9 I/M button
Quick test for inspection and maintenance
10 READ DTC button
Reads out the vehicle fault memory directly.
MIL yellow > Malfunction indicator lamp on
MIL grey > Malfunction indicator lamp off
> not supported
> completed
> not completed
