R911334336 | PSI 6xCx.225
I: Spot selection
I: New spot selection
O: Gun Force selection
O: Spot selection taken over
I: Program start
Sequence
O: Weld complete
O: Timer ready
9

Timer diagrams

Fig. 5: Sequence without fault, single spot
Bosch Rexroth AG 71/83
Timer diagrams
