B1.5 Electrical checks after installation
After connecting the filter to the power supply, the display will automatically turn on; the filter reaches
the filtration stage and the display switches off. After this stage, check the operation of the circuit by
manually pressing the buttons
backwashing procedure. Check the correct functioning of the backwash solenoid valve, if installed
(optional). The solenoid valve is in closed position during the backwashing operations performed by
the filter and in open position during filter operation.
B1.6 Allowed assembly diagrams
It is essential to install the filter respecting the water flow direction; water is fed from
the left connection while water output takes place from the right connection, keeping
the filter with the front logo facing you. In case you want the filter to be configured with
water feeding from the right side and water output from the left side, this configuration
has to be requested upon order. Any other configuration may result in the incorrect
operation of the equipment.
The filter drain connection must be conveyed into a visible drain in a stable manner.
In case of doubt contact with Acqua Brevetti SRL (Tel.: +39.049.8973432 or send an e-mail to
servizi@acquabrevetti.it
B1.7 Installation of the washing solenoid valve (optional)
The closing solenoid valve must be installed on the filter outlet connection (see item 8 of the example
B of the installation diagrams).
To manage the closing solenoid valve, the control panel is required (see item 9 of the example B of
the installation diagrams). The manufacturer makes available the optional control panel (code
23022030).
PuliMATIC - ENGLISH
simultaneously, until the motor starts; the filter performs a
