ISC RAD Bedienungsanleitung Seite 5

EN358:2018
Belts and lanyards for work positioning and restraint. Adjustable lanyards. For use ONLY with RAD Rope
Lanyard 11mm. Max user weight 150kg.
Work positioning or restraint:
• Must be used with a belt or harness conforming to EN358 or EN813 or EN361.
• The fixing screw must remain in place for use in this category, preventing the rope from being removed.
• Can be used in double mode as a pole strop, with connectors clipped to 2 side 'D's on the waist belt, or
both connectors clipped to a ventral attachment point. Fig 9
• Can be used in single mode, with the rope connector to an anchor, and the device connector to an
appropriate attachment point. Fig 10
• One handed adjustment is possible in double mode if the operative takes care. The tail end MUST be
held when adjusting the length in single mode.
Fig 9
Attachment Point - e.g. Harness
Fitting Instructions For Replacement Lanyard:
Fig A
Fig C
Close swivel plate and
re-insert lock screw
RAD: Issue C - November 2022
Fig 10
Attachment Point - e.g. Harness
Fig B
Open swivel cheek
plate to allow loading
of rope and load rope
around main cam
5
