C Use
EN12481:2006-C
Rope access systems. Rope adjustment devices. For use with 10.5mm to 11mm diameter EN1891 Type A
rope. Max user weight 130kg.
Descending or lowering:
• The fixing plate screw does not need to be in place for use in this category.
• Open the front swivel plate.
• Insert the rope as shown in Fig 1, also indicated on the device.
• Close the swivel plate and insert a EN362 connector through both holes. Fig 2
• Attach to the Ventral attachment point for use as a descender, or to an appropriate anchor for use as a
lowering device.
• Operate the handle to control descent. Fig 3
• ALWAYS hold the tail end of the rope when operating the handle.
Fig 1 Fig 2
Fig 3
Attachment Point - e.g. Harness
3
RAD: Issue C - November 2022
