Operating Instructions VC 1000

6 Operation

6.1 Selecting the operating mode

Pressing the PROG key switches to the next program and to manual mode
Manual: In this mode, the dispense time does not get saved and the VC 1000
dispenses as long as the dispense signal is activated by one of the
following:
footswitch / purge key / I/O-start
After dispensing, the dispense time starts again at 0 00 sec
PROG 1-7: If one of the seven programs is selected, the VC 1000 dispenses as long as
the value of the dispense time is set for This dispense cycle is activated by
one of the following: footswitch / purge key / I/O-start
This mode should be selected, if the rotary valve should always dispense for
the same time

6.2 Set the dispense time

The dispense time can be selected with the UP and DOWN keys, and set from 0 01 -
999 99 sec

6.3 Activating the Teach-In function

The Teach-In function is only available in the manual operation mode
When this function is activated each dispensing activity adds more dispensing time to
the actual interval (and not set back to 0 00 sec )
Thus you can approach to a dispensing time interval and material amount when you es-
tablish a new dispensing procedure These value can be saved to one of the preinstalled
programs To reset the timer to 0 00 sec press SAVE and DOWN key at the same time

6.4 Activating the Cycle mode

When the device is in cycle mode a single signal starts a continous loop of dispensing
processes The dispender runs a predefined cycle of exhausting compressed air and
waiting time (see next topic - IDLE time) This looping process can be stopped by
sending an other start signal via PURGE key, footswitch or external signal from I/O-port
