Operating Instructions VC 1000

11.3 Circuit diagrams

Digital inputs:
The input signal is active when the
optocoupler is switched on
The inputs are activated when the
input pin is short-circuited to the GND
pin
Digital outputs:
If the digital output is set,
the optocoupler is conducting
Foot switch:
The footswitch input signal is activated
when the input pin is short-circuited to
the GND pin
Do NOT apply an external supply
voltage to these pins!
This can lead to defect and damage
to the device.
VC 1000
VCC
Input
Microcontroller
GND
VC 1000
Output
Microcontroller
VC 1000
Input
Microcontroller
33
VIEWEG
VCC
Opto-
coupler
D2
GND
Opto-
coupler
GND GND
4k7
33R
WS
SW
GND
EN
I/O-Port
Input
I/O-Port
Output
1
Foot-
switch
3
