Operating Instructions VC 1000
11 Electrical connections
11.1 I/O-Port
type:
pins:
Pin No Input / Output
1 --
2 --
3 --
4 Output
5 --
6 Input
7 Input
8 Input
9 --
10 --
11 Output
12 Output
13 Input
14 Input
15 Input
External Program select: (assumed by REMOTE input signal)
Program No.
Manual
Program 1
Program 2
Program 3
Program 4
Program 5
Program 6
Program 7
15-pol Sub-D female 2-doublerow
see following chart
Description
Reserved
GND
24V DC
BUSY
GND
START
PRG 1
PRG 3
Reserved
Reserved
READY
ERROR
REMOTE
ERROR-IN
PRG 2
PRG-Selectbit #1
0
1
0
1
0
1
0
1
Comment:
Reserved
GND
24V DC
Dispensing procedure active
GND
Starts dispensing
Program select Bit #1
Program select Bit #3
Reserved
Reserved
Ready signal
Error signal
Remote active
External Error input
Program select Bit#2
PRG-Selectbit #2
0
0
1
1
0
0
1
1
