Varyscan* 4 1200 HMI
Occupation DMX-In / DMX-Out
Position of sockets see page 5
DMX-IN
Pin1: ground black
Pin2: DMX- beige
Pin3: DMX+ red
Pin4: frei
Pin5: + 5V green

Technical data

Measurements:
Weight:
Power consumption: ca. 1725W
Mains Voltage:
Bulb :
Fuse:
Change of Eprom/ Software Update
To change the Eprom proceed as follows:
Remove the cover sheet for the electronic board below the mirror by taking out the 4 screws
(see sketch page 36). By comparing the electronic board with the plan of electronic parts you
can see the Eprom at the right side (IC U2). Carefully lever the used Eprom from the holder and
exchange it for a new one.
Direction: Pay attention to the polarity of the Eprom!
DMX-OUT
Pin1:
Pin2:
Pin3:
Pin4:
Pin5:
hight 100cm
width 34cm
depth 24cm
36 kg
230V 50Hz 7,5A kompensiert
Osram 1200 HMI
16 ampere inert
ground
DMX-
DMX+
frei
frei
62
black
beige
red
