Varyscan* 4 1200 HMI
Attention: Do not use too much oil!
General Informations about DMX512 Record
DMX512 record is devided in 512 addresses. You have 512 addresses to your disposal. To be
able to connect different appliances with a DMX-controller, it is necessary to determine the
number of DMX-channels for every appliance. The occupation of channels of a scanner could
be like that for example:
channel 1
channel 2
channel 3
channel 4
channel 5
channel 6
In order that not every connected DMX-appliance performs same functions, the appliances are
addressed in series; i.e. for the first appliance the first 6 addresses are used (be right for an
appliance with six channels), for the second one (appliance with six channels) the next 6
addresses of all the DMX-addresses are used (see for example Varyscan* page 10).

Occupation of Channels for Varyscan* 4 1200 HMI

1. JB lighting 8 channels
Channel 1
Channel 2
Channel 3
Channel 4
Channel 5
Channel 6
Channel 7
Channel 8
channel 1 = x (pan) 170°
channel 2 = y (tilt) 90°
x-movement
y-movement
gobo/effect wheel
colour
shutter/dimmer
iris/gobo positioning/gobo rotation
X-movement
Y-movment
gobo
color
shutter / dimmer
iris
rotating gobos (positioning and rotating)
effect wheel
54
