Varyscan* 4 1200 HMI
All remaining DIP-switches SW9 SW8 SW7 SW5 SW2 stay in position "OFF".

Changing of gobos

Open the lid with the label Varyscan* 4 1200 HMI, by screwing off the six screws. Now you are
able to press the gobos at the gobo wheel out of their holder and then put in other gobos. Take
care that the gobo engages exactly with it's slits in the holder. If the gobo is put in correctly, it
moves easily inside the holder. Now you can close the lid.

GOBO measurements

With your Varyscan*, you have the chance of using two different gobo sizes.
50
