Varyscan* 4 1200 HMI
channel 2
channel 3
channel 4
channel 5
channel 6
channel 1 = iris and gobo rotation
iris closed / gobo first position
iris open / gobo first position
second gobo position
third gobo position
..........
locked into position 360°
locked into position 540°
rotation left highest speed
rotation left lowest speed
rotation stop
rotation right lowest speed
rotation right highest speed
channel 2 = colour
colour 0 (white)
colour 1
colour 2
colour 3
colour 4
colour 5
colour 6
colour 7
colour 8
colour 9
colour 10
colour 11
colour 12
colour 13
colour 14
colour 15
colour wheel rotation speed (slow)
colour wheel rotation speed (fast)
channel 3 = gobo and effect wheel
white
artificial light filter
colour
gobo and effect wheel
dimmer / shutter
X-axis
Y-axis
57
DMX 0
DMX - 64
DMX 65
DMX 66
DMX 191
DMX 191
DMX 192
DMX 222
DMX 223 - 224
DMX 225
DMX 255
DMX 000 - 007
DMX 008 - 015
DMX 016 - 023
DMX 024 - 031
DMX 032 - 039
DMX 040 - 047
DMX 048 - 055
DMX 056 - 063
DMX 064 - 071
DMX 072 - 079
DMX 080 - 087
DMX 088 - 095
DMX 096 - 103
DMX 104 - 111
DMX 112 - 119
DMX 120 - 127
DMX 128 -
DMX 255
DMX 0 - 9
DMX 10 - 19
