4 MATRIX 410™ PARAMETERS LIST

4.1 OPERATING MODE

PARAMETER
OPERATING MODES
Operating Mode
Reading Phase ON
Acquisition Trigger
(Phase Mode)
Acquisition Trigger
Status
Acquisition Trigger
Period (ms)
(Phase Mode)
Reading Phase OFF
22
TYPE SEL STRING
1 1 ESC A A
4 12 ESC A B
4 13 ESC A C
1 1 ESC A P
0 ESC A G
4 14 ESC A D
HOST MODE PROGRAMMING
DATA
0 = One Shot
1 = Continuous
2 = Phase Mode
1 = Ext. Trig. Lead. Edge
2 = Ext. Trig. Trailing Edge
4 = Main Port String
8 = Auxiliary Port String
16 = Input 2 Leading Edge
32 = Input 2 Trailing Edge
64 = Ethernet String
128 = Ethernet IP Input Leading Edge
256 = Ethernet IP Input Trailing Edge
512 = Fieldbus String
1024 = Fieldbus Input Leading Edge
2048 = Fieldbus Input Trailing Edge
4096 = ID-NET String
1 = Continuous
2 = Multi-Delay
4 = Periodic
8 = Input 2 Leading Edge
16 = Input 2 Trailing Edge
32 = Main Port String
64 = Auxiliary Port String
128 = Ext. Trig. Leading Edge
256 = Ext. Trig. Trailing Edge
512 = Ethernet String
1024 = Ethernet IP Trigger Leading Edge
2048 = Ethernet IP Trigger Trailing Edge
4096 = Fieldbus String
8192 = Fieldbus Input Leading Edge
16384 = Fieldbus Input Trailing Edge
32768 = ID-NET String
0 = Always Enabled
1 = Enabled When Input 2 Open
2 = Enabled When Input 2 Closed
Range: 17 to 60000
1 = Ext. Trig. Leading Edge
2 = Ext. Trig. Trailing Edge
4 = Main Port String
8 = Auxiliary Port String
16 = Input 2 Leading Edge
32 = Input 2 Trailing Edge
64 = Timeout
128 = Complete Read
256 = Ethernet String
512 = Ethernet IP Input Leading Edge
1024 = Ethernet IP Input Trailing Edge
4096 = Fieldbus String
8192 = Fieldbus Input Leading Edge
