2 PROGRAMMING COMMANDS
2.1 CONNECTION TO DEVICE
DESCRIPTION
1
Enter Host Mode
After entering this command, the device responds with the first reply message and
then waits for the following command.
2
Enter Programming Mode
After entering this command, the device responds with the second reply message
and or one or more programming strings as shown in Chapter 3.
2.2 DISCONNECTION FROM DEVICE
DESCRIPTION
End of Single Parameter
1
Programming Sequence
This message must always be transmitted after each escape programming string
(refer to paragraph 3.2).
If the programming is correct, the device confirms with the first reply message. If
programming contents are wrong (i.e. a typing error in the programming string) or
due to a transmission error, Matrix replies with the second error message.
Exit Programming Mode and
2
Data Storage
This command must always be transmitted to exit from programming mode.
It defines whether the configuration will be saved in the temporary (RAM) or permanent
(FLASH) memory (refer to paragraph 3.4).
If the programming is correct, the device updates the configuration and confirms with the first
reply message. If programming contents are wrong (i.e. a typing error in the file) or due to a
transmission error, Matrix replies with the second error message and programming data will
not be updated in this case.
3
Exit Host Mode
This command must always be transmitted to end the programming session. On exit
from Host Mode, the device is initialized with the new programming already saved in
the temporary and/or permanent memory.
End of Single Parameter Get
4
Sequence
This message must always be transmitted after each escape getting string (refer to
paragraph 3.3).
If the getting string is correct, the device reply with the current value of the parameter (refer
to paragraph 3.3).. If getting contents are wrong (i.e. a typing error in the programming
string) or due to a transmission error, Matrix replies with the second error message.
2
HOST COMMAND
<ESC> [ C
<ESC> [ B
HOST COMMAND
<ESC> I A #
<ESC> I A !
<ESC> I A <space>
<ESC> [ A
<ESC> I D #
HOST MODE PROGRAMMING
REPLY MESSAGE
<ESC> H <CR><LF>
<ESC> Q <CR><LF>
REPLY MESSAGE
<ESC> K <CR><LF>
<ESC> W 1 <CR><LF>
<ESC> K <CR><LF>
<ESC> W 1 <CR><LF>
<ESC> X <CR><LF>
<ESC> CH1 CH2 DATA
<ESC> I A #
<ESC> W 1 <CR><LF>
