Thus, this function is to be activatedonly when the pool water temperature is likely to decrease
spontaneously.
When this function is active, the set temperature can be chosen between 18 and 40°C.

The cooling function
under the set value due to the ambiant conditions, the heatpump keeps off, and will not heat the water.
Thus, this function is to be activated only when the pool water temperature is likely to increase
spontaneously.
When this function is active, the set temperature can be chosen between 18 and 30°C.
The indicator showing the active function is displayed left in the upperpart of the screen when unlocked.To modify it,
press once or several times until the icon of the expected function is displayed.
Note :the function ultimately selected by the operator will be active when restarting the heat pump after being off.
VI.3) Selecting the set temperature value :
Screen being unlocked, press
arrows.
VI.4) Selecting the operating mode :
The heat pump has 2 operating modes, each has its own specific advantages:
Mode
Smart
Silence
When the heat pump is started up (by pressing the On/ Off button), it enters SMART mode by default (the
corresponding icon is displayed on the screen)
Press the key to switch to SILENCE mode (the corresponding icon
To revert to SMART mode, press the key
Pressing this key will toggle between the two operating modes.
VI.5) Defrosting (heating and auto functions only)
The heat pump is designed such as it automatically detects when a defrosting cycle is needed. In such a case, the
defrosting cycle starts, and stops automatically.
When the heat pump is busy heating the water, the operator can also starts a defrosting cycle manually if it appears
suitable (for example, where a high amount of frost has not been totally eliminated by the defrosting cycle). For this,
press and simultaneously for 5 seconds.
flashes during a defrosting cycle.
only enables to decrease the water temperature. If the water temperature falls
or to display the set temperature, and then to change its value with these same
Recommandation
Standard operating
mode, used to raise
the pool water
temperature to the set
point
Proximity of
neighbourg
again.
Caractéristiques
Heating power is modulated between
25% and 100%, to heat or cool the
water rapidly if a high power demand is
detected
Heating power is modulated between
25% and 80%, the machine's noise
emission sound output is reduced 3dB
(A) compared to operation at 100%
power
is displayed on the screen)
2019/11– C - Code : 33315
35 /76
