Technical Details
Outside measurements:
Inside measurements:
Weight:
Electricity consumption:
Water consumption:
Working temperature:
General recommendations
>>
Clean the humidity filter (1), water tank (2) and air inlet grilles (3) every two months or as
required (see page 20).
>>
The humidity filter (1) should be changed at least every 2 years, or sooner if environmental
circumstances so require.
>>
Emptying the water from the circuit is recommended in winter, in order to avoid damage
from frost.
>>
Parts (A and B) should also be installed to prevent outside air from entering the passenger
compartment (see page 20).
>>
The air inlet must be covered with parts (A and B) if the unit is to be cleaned with a pressure
hose. These parts must be removed when the unit is put back into operation. (See page 20).
Water treatment
The IRIS ecological cooler includes a biocide core (2A) (see page 19) for water treatment,
prepared in accordance with current regulations; this maintains ideal water conditions for 6 months,
reducing the formation of incrustations caused by impurities and corrosion, while preventing the
proliferation of fungi, bacteria, etc. that could be harmful to health.
The biocide core is located inside the water tank, meaning it is always in contact with the water
at the bottom of the circuit.
To replace the biocide core (ref. 091252C014 - see page 19), first take down the part (2A) and
then replace the expired core with a new one. Replace the tank sticker (3) and mark the product
installation date, in order to be sure when it expires.
Contact the official distributor to purchase the replacement.
870 mm (long) x 795 mm (wide) x 24.5 (high)
450 mm x 450 mm x 54 mm
19 kg
3 -11.3 A
0.7 - 1.7 l/h
Max. 55ºC air temperature
USER'S HANDBOOK
IRIS
EN
17
