Technical data

Techni-
Dimensions
cal data
Weight
Material
Protection class
Supply voltage
Current consumption
(average values)
Fuse protection
Temperature
GSM
GPS
TM
Bluetooth
Ignition input
Digital input
GPS antenna
connector for
external GPS antenna
(optional accessory)
Body: 85 x 67 x 24 mm / Holder: 55 x 66 x 30 mm
Body: 95 g / Holder: 10 g
Body and holder: Injection moulded plastic PC/ABS
IP 20
12 V / 24 V (min. 9 V to max. 30 V)
At 14 V: typically < 50 mA
At 28 V: typically < 30 mA
Standby: typically < 1 mA
During data transmission
14V < 180mA
28V < 100mA
Operating voltage 9 - 30 V with 2 A / fast blow fuse*
Ignition with 2 A / fast blow fuse*
* Mini Fuse Fast-Acting 2A (manufacturer Littelfuse, Part No. 297 002) and
Mini Fuse Easy-Crimp In-Line Fuseholder (manufacturer Littelfuse, Part No.
153002)
Operation: -30 °C to +70 °C
Storage: -40 °C to +80 °C
Integrated GSM antenna and GSM module
Quadband GSM 850 / 900 / 1800 / 1900
Integrated GPS antenna and GPS receiver
TM
Integrated Bluetooth
To be connected to the ignition clamp to switch on/off device together with
ignition
1 input switchable to supply voltage
SMB (male) - (antenna - female)
Supply voltage range 3 V to 5 V
Minimum antenna gain at 3 V: 20 dB
Maximum antenna gain: 40 dB
Maximum noise rating: 1.5 dB
(class 2) for connection to GO 7000
